Today, the compactness and limitations of the 4×8 CNC router table are exposed in full-size machining as modern industrial manufacturing requires larger automated table kits. In this case, the 5×10 CNC router machine has evolved into the most popular woodworking tool for cabinet and furniture making in the United States, Canada, Australia, the United Kingdom, and some EU countries. The 5′ x 10′ CNC router table kit is large enough to handhle most modern woodworking projects, working with a linear automatic tool changer to maximize woodworking automation, a vacuum table to hold the workpiece more firmly, and a dust collector to keep wood chips out.
What Is 5×10 CNC Router?
5×10 CNC router is a type of full-size automatic CNC machine with 5′ x 10′ (60″ x 120″) table kit for industrial manufacturing and commercial use with heavy duty structure, 9KW HQD ATC spindle, Leadshine servo motor 1500W + reducer, LNC CNC controller system, linear automatic tool changer kits. The 5×10 feet table size is large enough to cut and mill full size sheets. The CNC controller is user friendly and easy to use, compatible with Type3, ArtCam, Ucancam, Castmate, and more CAD/CAM software.
Features & Advantages of Industrial 5×10 CNC Router Table with Tool Changer
• Sturdy steel tube construction bed features a heavy-duty design for a solid structure and stress relief for a more stable workbench.
• 9.0KW air-cooled ATC spindle is easy to use without water pump required.
• High-performance 1500W servo motor runs smoothly with strong overload capability.
• Linear automatic tool changer kit with 12 tools for fast and reliable changes.
• Automatic lubrication system for maintenance of ball screws, positioning bearings and linear guides.
• The breakpoint memory feature allows the machine to continue cutting after a power outage and predicts the processing time.
• Compatible with Artcam, Type3, Castmate, Ucancame, and other CAD/CAM software.
Technical Parameters of Industrial 5×10 CNC Router Machine with Tool Changer
| Model | STM1530C |
| Working Area | 1500x3000x300mm |
| Table Size | 5′ x 10′ |
| Traveling Positioning Accuracy | 0.03/300mm |
| Repositioning Accuracy | 0.03mm |
| Table Surface | Vacuum and T-slot Combined (Option: T-slot table) |
| Frame | Welded structure |
| X, Y Structure | Hiwin Linear Rail, Helical Rack & Pinion Drive, |
| Z Structure | Hiwin Linear Bearings & Rails, TBI Ball Screw |
| Max Rapid Travel Rate | 50000mm/min |
| Max Working Speed | 30000mm/min |
| Spindle Power | Air Cooling ATC Spindle 9KW |
| Spindle Speed | 0-24000RPM |
| Drive Motors | Leadshine servo motor 1500W + reducer |
| Working Voltage | AC 380V/50/60Hz, 3PH or AC 220V/50/60Hz |
| Command Language | G Code |
| Operating System | LNC CNC Controller |
| Flash Memory | 128M |
| Collet | ER32 |
| X,Y Resolution | <0.03mm |
| Software Compatibility | Type3 and Ucancam software (Option: ArtCAM Software) |
| Running Environment and Temperature | 0 – 45 Centigrade |
| Relative Humidity | 30% – 75% |
How Much Does A 5×10 CNC Router Cost?
If you’re looking to upgrade the woodworking business you are running, or would like to make money on custom carpentry projects with a full-size CNC machine, you should consider adding a professional 5′ x 10′ CNC machine with automatic tool changer to your woodworking line or workshop. So how much money do you need to invest in it? Is it expensive? Is it worth buying? According to authoritative statistics, the average cost of buying a 5×10 CNC router in 2026 is $7,280, depending on the features and configuration, including the working table (T-slot table or vacuum table), CNC controller with software, gantry, spindle, guide rail, ball screw, vacuum pump, motor, driver, software, collet, 4th rotary axis, power supply, limit switch, rack and pinion. 5′ x 10′ CNC router kits from different manufacturers and brands have different customer service and support, which will lead to different costs. 5×10 CNC machines from different countries have different different shipping costs, different customs, and tax rates. All will result in the final price.
Most entry-level 5×10 CNC router kits for beginners start at $5,080 and go up to $6,280, while professional 5×10 CNC router table kits with multiple spindles range from $6,380 to $12,000, and industrial 5′ x 10′ CNC router machines with automatic tool changer can cost anywhere from $13,800 to $223,000. In addition, a smart 5′ x 10′ CNC machine with automatic nesting and feeding system for a panel furniture production line is priced over US$25,000.
Details of Industrial 5×10 ATC CNC Router Machine with Linear Automatic Tool Changer Kit
5×10 CNC Machine with Automatic Tool Changer in Factory.
Automatic Oil Lubrication.
LNC CNC Controller Software.
Linear Automatic Tool Changer Kit.
9KW HSD Air Cooling Spindle for option.
Industrial 5×10 CNC Router Table Applications
Applicable Materials
Wood, MDF, plywood, acrylic, artificial stone, artificial marble, bamboo, organic board, double-color board, PVC board, copper, aluminum, brass, and other materials.
Applicable Industries
Woodworking: Home doors, windows, beds, cabinets, tables, chairs, kitchenware, exquisite european furniture, redwood classical and antique furniture, decorative products sculpture.
Artworks & Decorations: Wood crafts, jewelry box, gift box, and more exquisite arts & crafts.
Music Industry: Musical instruments and loudspeaker box.
Mold Making: Copper molds, aluminum molds, metal molds, building models, shoe molds, badge molds, biscuit, chocolate molds, embossed molds, candy molds, plastic sheeting, artificial marble, wood, foam, PVC, and more nonmetal mold.
Advertising: Signage, logo making, company plate, sign making, emblem, badges, building numbers, lightbox, acrylic cutting, display panels, decorations, LED/Neon channel, billboard, 3D letters cutting, literal hole cutting.
